Why do you need a 250 ohms resistor in HART protocol?
By Matthew Underwood
The voltage (IR) drop needed for HART communications is produced by the resistance at the loop receiver's analog input. A 250 ohm resistor is commonly used because 250 ohm resistors work for that purpose and are typically available in the instrument shops where these types of bench tests are done.
.
People also ask, what color is a 250 ohm resistor?
For example, a resistor with a color band pattern of red, green, yellow, gold yields the first digit as 2, the second digit as 5, and a multiplier of 10,000. This produces a resistance value of 25 * 10,000 = 250 kΩ with a ± 5% tolerance.
Subsequently, question is, what is HART communicator used for? A HART communicator is a portable device, based on HART communication protocol. A field communicator supports both HART and Foundation Fieldbus devices. HART communicator devices are used to check variables online and for calibration purposes.
Besides, how is Ohm's law useful as a technician?
Probably the most important mathematical relationship between voltage, current and resistance in electricity is something called “Ohm's Law”. This formula is used to calculate electrical values so that we can design circuits and use electricity in a useful manner. Ohm's Law is shown below.
What is the formula to calculate resistance?
If you know the total current and the voltage across the whole circuit, you can find the total resistance using Ohm's Law: R = V / I. For example, a parallel circuit has a voltage of 9 volts and total current of 3 amps. The total resistance RT = 9 volts / 3 amps = 3 Ω.
