What is Cisco DirSync service?

What is Cisco DirSync service?

LDAP synchronization uses the Cisco Directory Synchronization (DirSync) tool on Cisco Unified Communications Manager to synchronize information (either manually or periodically) from a corporate LDAP directory. You use the LDAP directory interface to create and manage user accounts.

How do I restart CUCM service?

Restart the CallManager

1. Log in to Cisco Unified Serviceability on the CallManager.
2. Select the Tools drop down and Control Center – Feature Services.
3. Select CallManager/Server IP and click Go.
4. Under CM Services, select Cisco CallManager.
5. Scroll to bottom and select Restart to restart the service.

How does Cucm sync with Active Directory?

Steps

1. Create a CUCM user in active directory.
2. Enable Dir sync on your call manager.
3. Configure LDAP system settings.
4. Configure the LDAP Directory information.
5. (optional) enable LDAP authentication.
6. Perform a full sync now.

How do I check my Cucm uptime?

Basic check-up of a CUCM server

1. show status. If you need to analyse any problem, this is the first command to begin with.
2. show tech network hosts.
3. utils ntp status.
4. utils service list.
5. utils dbreplication runtimestate.
6. run sql SELECT count(*) from enduser.
7. utils core active list.
8. file dump install system-history.log.

What is the difference between LDAP synchronization and LDAP authentication?

–> LDAP Synchronization works differently compared to LDAP Authentication. –> All the End-user information is replicated to CUCM Database from LDAP Server in LDAP Synchronization. –> End users are authenticated on CUCM Server instead of Active Directory as the database is replicated to CUCM in LDAP Synchronization.

How do I restart DRF service Cucm?

Complete these steps in order to resolve the issue:

1. Log into Cisco Unified Communications Manager OS Administration page.
2. Choose Security > Certificate Management.
3. You can use the Find controls in order to filter the certificate list.
4. Click the ipsec.pem file, and then click Regenerate.

How do I turn off Cucm?

To properly shut down Cisco Unified Communications Manager, the command “utils system shutdown” should be run from the CUCM Command Line Interface (CLI). CUCM virtual machines should not be abruptly stopped using the square stop button that you will see in the VMWare console.

How do I remove inactive LDAP synchronized user from Cucm?

Step 1: Login in the CUCM publisher CLI. Step 3: Change status to active. Step 6: Find the newly activated user, e.g. 411001 and convert to a local user. Step 7: Once converted to a local user you can delete the user.

How do I run LDAP sync in Cucm?

Configure LDAP in Cisco Unified Communication Manager

1. Go to System > LDAP > LDAP System.
2. Check Mark > Enable Synchronizing from LDAP Server.
3. LDAP Server Type > Microsoft Active Directory.
4. LDAP Attribute for User ID > sAMAccountName.
5. Click on Save.
6. Go to System > LDAP > LDAP Directory.
7. Click on Add New.

How can I check my Cucm service status?

To verify that all the activated services are running, from the menu select Tools > Control Center – Feature Services. On this page the status (Started or Not Running) and activation status (Activated or Deactivated) of each service can be checked.

What happens when Cucm publisher goes down?

RE: NTP – CUCM Publisher is Down Just go ahead and rebuild and restore the pub and your clocks will reset. Shouldn’t take you more that 3-4hrs to restore the publisher and failover the phones to it.
