How do I connect my water supply to my irrigation system?

Connecting a Lawn Irrigation System to a Home Water Supply

1. Tap the outside faucet. Unscrew the outside faucet and install a 1-inch galvanized or copper tee fitting facing down.
2. Tapping the main line. Cut a section out of your main line and install a compression tee fitting.
3. Tapping the basement water meter.

.

Also, where is the water shut off valve for my sprinkler system?

Locate the main shutoff valve on your irrigation system. It is between the main water supply to your home and the sprinkler controller. Alternately, the main shutoff is located outdoors near a faucet bib. The main valve may be in a box in this area to protect it from the elements.

Similarly, how do you set up an irrigation system?

1. plot types and locations of sprinkler heads. Plan the System.
2. install an anti siphon valve. Access the Water Line.
3. dig the trench for system.
4. attach one end of valve manifold assembly to water.
5. attach risers using 90 degree connectors.
6. level sprinkler heads with soil level.
7. timer controls length and frequency of waterings.

Then, how do you tap into the main water line?

how to Tap Into The Main Water Supply Line

1. Shut off your water supply at the meter.
2. Dig to expose the service line.
3. Tie into the service line, between.
4. Remove a section of pipe, leaving a gap.
5. Slip the tee over each end of the pipe.
6. Tighten the compression nuts.
7. Install a short nipple, using PTFE tape on all threaded connections to the tee.

How do I shut off water to sprinkler system?

STEP 1: Shut off the water to your sprinkler system. The shutoff valve is often located in the basement, a utility room or closet. Most shutoff valves are ball valves that have a handle. If the handle is running with the pipe, the water is turned on to the system.

Related Question Answers

How do I find a sprinkler head without water?

How to Find Buried Sprinkler Heads

1. Turn on your sprinkler system using its controller.
2. Measure the distance between active heads using a tape measure.
3. With the entire sprinkler system activated, identify blind spots in coverage.
4. Probe blind spots with the tape measure and spade.

Can a sprinkler system leak when off?

There are two reasons why a sprinkler will leak water when the system is supposed to be off. The most common reason is called “Low Head Drainage”. If it is low head drainage, residual water will stop flowing after all the water has left the pipe.

How do you turn off a sprinkler valve?

One way is to simply turn the solenoid (the black cylinder with 2 wires) counter-clockwise a 1/4 to 1/2 turn. To shut off the valve, twist the solenoid clockwise until it is snug on the valve. The other way is to use the bleed screw the same way, loosen the screw enough to realease air (1/4 to 1/2 turn).

Why does my sprinkler system keep running?

There are two reasons why your sprinklers would continue running: It's possible your valves have been opened manually. You'll need to locate your valve box(es) and turn the solenoid(s) clockwise until snug. The solenoid is located on the top of the valve and looks like a cylinder with two wires protruding out of it.

How do I winterize my sprinkler system?

Then turn off the water supply and set the system timer to open just one zone. Next, open the manual drain valve at the end of that zone (if equipped). Then, connect the air line to the blow-out port as shown. Connect the other end of the air hose to the compressor and blow out the line.

How do I connect an existing water line?

The most common way to connect a new drain, vent, or supply line to an existing line is to install a tee fitting. To do so, shut off water to existing supply pipes and drain the lines. Flush all toilets and caution others not to use drains.

Can you run a sprinkler system off a hose bib?

By connecting a "Y" shaped hose connector to your hose bib, also called a faucet, you'll also be able to use the bib for hooking up a sprinkler for the kids without disturbing your sprinkler system.

How deep should irrigation lines be buried?

Basic Depth Requirements In most areas, burying the pipes 8 to 12 inches below the surface is adequate. This measurement is from the top of the pipe to the surface of the soil, which means your trenches must be slightly deeper to accommodate the pipes.

Where does the main water line enter a house?

Your main water supply line enters your home at ground level or below. In warm weather zones, the line usually sticks up out of the ground just outside the home and then enters the side of the house.

Can I use PEX for main water line?

No. You can install PEX fittings supply just like you would other pipe, with main lines and branches to each fixture. But you lose a lot of the benefits of PEX supply with this system since it requires so many fittings. PEX water line supply tubing to each fixture.

What is wet tapping water main?

A wet tap connection refers to the connection made into a New York City water main (or any public water main) for a water service line installation. Usually such a connection is for one individual property.

How do you hook up a refrigerator water line?

Drill a hole either through the cabinet wall separating the space under the sink and the refrigerator or in the basement ceiling up to the refrigerator. Thread copper tubing through the hole you just drilled. Attach one end of the copper tubing to the refrigerator's water pipe, using a nut and ferrule.

What size pipe should I use for a sprinkler system?

For schedule 40 PVC, use 1/2-inch pipe for a 4 GPM system, 3/4-inch pipe for 8 GPMs, 1-inch pipe for 13 GPMs, 1 1/4-inch pipe for 22 GPMs, 1 1/2-inch pipe for 30 GPMs, and 2-inch pipe for 50 GPMs.

What is the best irrigation system?

Orbit 69525 Complete Drip Irrigation Watering Kit It's easy on the plants and provides uniform coverage of the whole garden, taking perfect care of all your trees, shrubs, and flowerbeds. With a coverage of up to 250 square feet, the Orbit 69525 is arguably one of the best irrigation system money can buy.

How long can a drip irrigation line be?

LENGTH OF RUN LIMITS: ½ inch tubing can run up to 200 linear ft. ¼ inch tubing should not exceed 19 ft in length. MAXIMUM FLOW CAPACITY: ½ tubing can handle a maximum of 240 GPH or 4 GPM.

What is the purpose of irrigation?

Irrigation is the application of controlled amounts of water to plants at needed intervals. Irrigation helps to grow agricultural crops, maintain landscapes, and revegetate disturbed soils in dry areas and during periods of less than average rainfall.

How many zones do I need for my sprinkler system?

The resulting number will equal how many zones you need. If, for example, each sprinkler head will require a flow rate of 1.31 GPM and you have 20 of them, then you will need 26.2 GPM total. If your system can only handle 16.67, you will need to use two zones to cover that same area of your yard.

How do you hook up a sprinkler system?

1. plot types and locations of sprinkler heads. Plan the System.
2. install an anti siphon valve. Access the Water Line.
3. dig the trench for system.
4. attach one end of valve manifold assembly to water.
5. attach risers using 90 degree connectors.
6. level sprinkler heads with soil level.
7. timer controls length and frequency of waterings.

How do I fix my sprinkler system?

Once you locate the approximate leak site, dig straight down to the water line. Then enlarge the hole along the line, following the flow of the leaking water until you find the break or crack. Before making the repair, make sure the system is turned off at the controller. Use a slip coupling to repair the leak.
